News
BG = Correction
AM = Improvement
myCADtools 2024 SP2 :
New SmartBom Beta version
Added compatibility with SOLIDWORKS 2025
3DSpaceExplorer:
BG187040: The result is not the same between a general search and a search on a specific bookmark.
BatchConverter:
BG187425: Problem with "Sheet number" on DXF/DWG files
BG194419: Use of the Sheet name variable should take the name of each sheet for multi-sheet DXF/DWG export.
BG176345: SOLIDWORKS options are not saved in BatchConverter options
BatchProperties:
BG184701: Version "SOLIDWORKS 2024" is not retrieved from the BatchProperties file selection
BG190237: If a property with an empty value is added after other properties with values, then the empty property is not applied.
ColorChart:
AM180095: Added ability to add document properties and all configurations
AM184010: Added ability to redefine insert text
Field concatenation tool:
AM170817: Add part number displayed in BOM
AM173644: Add document format to field concatenation tool
AM181989: Separate naming bookmarks from path bookmarks
AM190856: Added option to retrieve "full name".
AM193168: Added a variable to retrieve the "Referenced file name".
BG193385: "File location" variable no longer works with a specific default naming rule
File selection tool:
AM182080: Add column to display depth level
AM184684: Add "No longer display" option to active files message
BG181860: If "Sort on today's date" is selected and a task is scheduled for the next day, the date is not updated.
BG189111: Unable to add some files with the message: "the active document does not match the chosen filter".
BG193510: Extraction and archiving no longer automatic in a specific case
CuttingOptimization:
AM180394: Added the option of exporting debit lists as Excel files
AM181346: Added the possibility of starting from the value of the selected marker
AM190869: Added option to apply color to profiles automatically after import
AM190876: Cut preview added to interface
AM190878: Addition of a detailed cutting report
BG179979: Error opening a project
BG181347: On some projects, it is impossible to add flow rates
BG181357: Incorrect dimensioning angle with angle dimensioning option
BG181359: Do not leave the cell when renaming a profile
BG181376: Problem in report when using a specific angle dimensioning option
BG185198: Unable to open report generated with PDFCreator driver
BG187071: 3D import crashes on SOLIDWORKS 2018
BG191257: The initial fall is always 100 minimum in the report, despite the fact that a lower value is applied.
DataRecovery:
BG187773: When generating an Excel sheet from a 3DEXPERIENCE extraction, the sheet is in protected mode.
BG189747: You can't select an Excel file if you select the import option without going through extraction.
BG189751: Excel file encounters value display problem when there are significant zeros in a property
FindDocuments:
AM182005: Show lost or other dependencies in sub-levels
AM187147: Modification of "Repair lost dependencies" option
AM184332: Added the ability to rename files with property rules using the field concatenation tool
AM187328: Separation of file information into tabs
BG190768: References are not repaired after a database update
BG190977: FindDocuments scheduling no longer works
Integration:
AM155186: Added ability to set multi-sheet options for each format
AM186504: Added field concatenation tool for location options
AM194429: Add possibility to count only 1st level components for condition: If assembly contains N component(s)
BG184211: The name option is not saved for the "Decline configurations" operation.
BG184212: Modify operation "Decline configurations and replace components" with reference reconstruction
BG184244: Abnormal operation "Place free text in report".
BG185468: Serialization problem on configuration operation "BOM options "N" part when used in a BOM".
BG187114: The syntax of a SOLIDWORKS variable is not correct with the "Test/read properties on active configuration and document" read option.
BG190788: Added operation to copy all properties
BG190936: Placing the condition test in a report does not work in case of failure
BG191770: "RealView management" operation generates report failure despite operation success
myCADpassport:
AM188773: CleanProject added to myCADpassport tools list
myCADtools:
AM186628: Addition of all administration tools in search
AM192590: Adding a context with included document on a new installation
AM162371: Added the ability to block new version notifications
BG186195: Problem with property.xml file when creating a new context
BG188040: The custom mask is recovered if SmartProperties is reset from myCADtools application with SOLIDWORKS open.
Settings management:
AM182216: Document management
AM191068: Added ability to rename a context
PilotAssembly:
BG180121: Table creation does not work on a specific file
SheetMetalManufacturing:
AM186503: Added field concatenation tool for location options
AM75653: Added ability to group sheet metal items with a common name or graphically in the interface
BG181627: Body property values are not correct if there are several identical parts in different configurations.
BG193726: Error opening tool when document template does not exist
BG194506: Sheet metal parts analysis error
SmartBalloons:
BG158120: Tool changes item numbering
SmartBom:
AM177646: Add the possibility of using SmartBom v1 or V2
SmartDrawings:
BG187572: No plan is created if the "Create detached plans" option is checked.
SmartProperties:
AM136866: Added ability to retrieve path from vault root without drive letter
AM183982: Use location of last file opened in SOLIDWORKS when selecting folder
AM186911: Added the ability to read the evaluated value of a 3DEXPERIENCE variable
AM188223: Added option to open a document when using the Create New Document and Save Copy As options
AM193045: Added ability to ignore PDM license message
AM60433: Added ability to uncheck linked properties for sheet metal parts from SmartProperties
BG102529: Counter value not updated in form if counter variable in radio button
BG149797: In multi-part selection, only one part is saved as a sub.
BG178263: You need to double-click the "set as path the location of the 3D document" button for the path to change.
BG191702: If the evaluated value of a dimension property is retrieved and the mask is validated again, the variable is overwritten by the text value.
BG193930: Problem with "Display in FeatureManager" option window on a dynamic menu when there are many lines
myCADtools 2024 SP1.2 :
General:
BG187864: Custom settings from previous versions are not recovered when installing version 2024
3DSpaceExplorer:
BG187041: Error message when retrieving a plan from 3DSpaceExplorer with the dependency option checked
myCADtools 2024 SP1.1 :
SmartCounter:
BG186765: Alphabetical cumulative counter no longer works
myCADtools 2024 SP1 :
CloneComponents:
BG184901: Display problem on latest version
BG185963: CloneComponents launch error
DataRecovery:
AM183039: Open Excel template favorites location directly
BG183463: 125% display problem
BG183475: Problem importing property when drop-down menu is set to NONE
FindDocuments:
AM147374: WhereUsed integration in FindDocuments
AM174055: Drag & Drop added
AM174057: Add assemblies to orphan analysis
AM174553: Take deleted components into account or not
AM174673: Add button to view report after processing is complete
BG179192: Error during file analysis
BG179923: Unable to return to "Local location" option if "I support update...." option is selected.
General:
AM185805: Translation enhancement
AM185807: German documentation added
BG29770: Unable to run a macro if SOLIDWORKS was started by a myCAD tool
myCADtools:
BG180846: Error when launching myCADtools with Windows scaling option enabled
AM183238: Added the ability to create a custom favorites tab
Field concatenation tool:
BG183277: Configuration information no longer retrieved
File selection tool:
BG183918: The file previously selected with the "Add active document" button is replaced by the new document selected with the same button.
BG183948: Regression - "Insert drawings" function no longer works for files retrieved from the 3DEXPERIENCE platform
BG183983: The file cannot be imported if it contains 3 different types in the list of welded parts.
ProjectManager:
BG184734: If a property is created and used in a renaming rule, the value is always set to "False" on duplication.
SheetMetalManufacturing:
BG180792: Annotations not centered on view when margin applied
SmartCounter:
AM183863: SmartCounterWeb added
myCADtools 2024 SP0 :
General:
New shared parameterization tool
AM182051: Taking contexts into account when creating default options
AssemblyBoard:
BG172220: Property import is empty in a specific case
BG182040: The quantity is not added to the annotations even though it is checked.
BatchConverter:
AM174767: Integration of the field concatenation tool in the location options for generated files
AM181495: Generated file location option interface modification
BG140993: Automate activation of configuration used by assembly for export
BG169988: "Export named sheet" option does not work for DXF files
BG174647: BatchConverter no longer works in TaskPlanner Mode
BatchProperties:
BG177937: When there is a property with an empty value in the property list, the properties that follow are not added to the document.
CuttingOptimization:
AM159083: Cut previews not correct when there are many of them
AM164513: Add the ability to configure the tracking number
AM166337: Hide profile name in "Positioning" section when importing from 3D
AM178072: Grouping identical bodies from different parents
AM182052: Taking contexts into account when creating default options
BG175171: Analysis problem when cut is shorter than section width
BG175688: Length imported by 3D import is wrong if body merge options are used
DataRecovery:
AM182597: Added option to manage evaluated values
FindDocuments:
AM176444: Added the ability to analyze only the search folder to identify external references between folders
BG180930: With some options in the "Analysis" tab, Excel export does not start
Integration:
AM161549: Added the ability to use syntax to apply a value containing $.
AM171430: Field concatenation tool added for operations
AM173250: Added ability to export sheet metal bodies
AM176287: Integration sample added for automatic insertion of visualization cube via macro
AM176297: Added the ability to use the rename tool for the "Create document plan by sheet" operation.
BG173580: Adding a Windows property does not work with the "Apply properties to all configurations" configuration option.
BG174501: Error loading Integration action file, conditions only loaded
BG177150: On a project with several actions including a "If sheet N is a format" condition, when the format is changed on one condition, the others are also modified.
BG178686: Esc closes tool
BG180730: The condition "if the document belongs to a specific folder" does not store the folder path.
myCADpassport:
AM179929: Add a shortcut to launch Indispensables tools
myCADtools:
AM176433: Add settings options
AM179302: Addition of a tab featuring the 7 must-haves
BG179301: Search does not reveal all tools
Field concatenation tool:
AM169635: Show multiple choice in list
BG177939: SOLIDWORKS variable "Density" is not retrieved
BG178351: Options window no longer present
BG179062: "The drag and drop of "fixed value" does not work.
BG179568: Crash after opening conditions
BG180858: Error message when modifying properties after changing condition options
BG181094: Crash when editing properties after deleting property lines in BatchProperties
BG181186: Plan property values are not retrieved on Connected 2024
File selection tool:
AM141572: Added ability to filter envelope components
AM159859: Added ability to load all open documents into SOLIDWORKS
AM172598: Added ability to exclude files in delete state
AM60637: Display missing files when dissolving a CSV file containing missing items
AM60802: Added a message to the PDM options in the file selection tool to indicate that a myPDMtools subscription is required to use these options.
AM66552: Added filter for sheet-metal and welded parts in the file selection tool
BG177225: If the "Part" and "Assembly" filters are unchecked, dependency drawings are no longer retrieved.
PilotAssembly:
BG160001: Tool remembers Excel process when driving a file containing equations
ProjectManager:
BG169827: Automatic plane search uses the path above the selected assembly path
SearchPaths:
BG161405: SearchPaths does not add paths to SOLIDWORKS unless the options window is opened in the SOLIDWORKS session launched by SearchPaths.
Setup/Installation:
AM176431: Setup migration in 2024
AM178993: Essentials training added to Setup
SheetMetalManufacturing:
AM169024: Added ability to have a drop-down menu for document template selection
BG175692: The exported sheet is empty when combining the following options: Group views by thickness/material on several sheets in a single file with the Separate by material option checked and the Separate by thickness option unchecked.
BG178392: If a file is generated by body and a body property is retrieved for the file name, the value taken is the same for all exports.
BG178685: Double-click on "Apply" to relaunch the tool after the report.
BG179066: Modification of the option "Do not recreate the 'SM-FLAT-PATTERN' configuration if it exists".
BG180787: Nothing is generated when combining the options: Group views by thickness/material over several files with the Separate by thickness option
SmartBom:
BG152819: PDF export files not added to PDM vault
BG176391: Translation enhancement
BG182454: In closed file mode, a component is not grouped with the others if the case of the file name has changed.
SmartCounter:
BG178495: In SmartProperties, the counter variable is not updated in the mask if the variable that exists in PDM also exists in the mask, the value applied is correct.
SmartDrawings:
AM66930: Error handling when SOLIDWORKS has been closed and processing is clicked on
BG153551: Malfunction in model object annotations
BG155100: Dimensions marked for parts drawing are not transferred to assembly drawing
BG165662: Tool crashes SOLIDWORKS on some files
SmartProperties:
AM176767: Added ability to ignore "Extract file if archived in PDM" message
BG174156: If nothing is selected on a "Rating" property, the value is not empty but equal to a space.
BG174452: Error message during validation if mask window pin is enabled and rename option is enabled
BG88214: SmartProperties displays the save as window twice if you rename an existing document and have the pin.
Tolerances:
BG163289: Regression - Manual selection no longer works
UpdateVersion:
AM164489: Add progress bar for analysis step
